Power supply module for DC CT which is used in diagnosis of inverter motor

It supplies isolated +/- 15 V power to each of the three DC SCTs

Easy connect with gems5200/5500  as a 3-phase DC CT

Both DIN rail and wall mount available

Compact size for installation in narrow spaces

(62mm x 96mm x 56mm)

Strong structure against dust using the removable top cover
