Automatic Voltage Stabilisers

optimise your energy consumption

Voltage Stabiliser Products

Servo Electronic Design

Indoor-IP20(21)/Nema 1;

SES, SES-R, SESL Series

Single Phase 1 - 100 kVA

Three phase 6 - 1500 kVA

Ideal for 95% of all general commercial and industrial applications

Features

  • Step-less automatic voltage regulation

  • Constant output voltage, no load to full load

  • High precision ±0.5% output voltage regulation accuracy

  • Wide range of permissible input voltage windows (up to ±0.5%)

  • Inbuilt by-pass control

  • Inbuilt transient voltage surge and spike suppression

  • Extremely low maintenance

  • Compliance with International standards

  • 3 year standard warranty

Brushless Magnetic Induction Design

Indoor (IP20): MVSI Series

Outdoor (IP54): OMVSI Series

Three phase Air-Cooled 200 - 1600 kVA

Robust industrial products suitable for the toughest environments

Features

  • Robust industrial products suitable for the toughest environments.

  • Ideal for Office Complexes, Production Processes & Plants, Broadcasting and Medical Equipment & Establishments.

  • Brushless air-cooled magnetic induction design

  • ±1.5% Output Voltage Accuracy

  • Permissible Input Voltage Window ±10% to ±40%

  • Start-up load protection

  • Front panel status monitoring

  • Over / Under Voltage Indication

  • Virtually Maintenance-free

  • Optional Main System Switch Board

  • Compliance with International standards

  • 3 year standard warranty

Servo Electronic Design

Outdoor-IP54/Nema 3;

OSES, OSESL Series

Single Phase 1 - 100 kVA

Three phase 6 - 1500 kVA

Ideal for 95% of all general commercial and industrial applications

Features

  • Step-less automatic voltage regulation

  • Constant output voltage, no load to full load

  • High precision ±0.5% output voltage regulation accuracy

  • Wide range of permissible input voltage windows (up to ±0.5%)

  • IP54 sheet steel enclosures

  • ​Start up load protection

  • Inbuilt bypass control

  • Extremely low maintenance

  • Compliance with International standards

  • 3 year standard warranty

Brushless Magnetic Induction Design

Indoor (IP20): IVSI Series

Outdoor (IP20):OIVSI Series

Three phase Oil-Cooled 500 - 3000 kVA

Robust industrial products suitable for the toughest environments

Features

  • Robust industrial products suitable for the toughest environments.

  • Ideal for Office Complexes, Production Processes & Plants, Broadcasting and Medical Equipment & Establishments.

  • Brushless oil-immersed magnetic induction design

  • ±1.5% Output Voltage Accuracy

  • Permissible Input Voltage Window ±10% to ±30%

  • Lightning surge protection

  • Front panel status monitoring

  • Over / Under Voltage Indication

  • Virtually Maintenance-free

  • Optional Main System Switch Board

  • Compliance with International standards

  • 3 year standard warranty




Introducing Ashley-Edison

Ashley-Edison’s success is based entirely on their ability to meet the requirements of customers dependably and cost-effectively. Today, where performance is everything, whatever your AC mains supply problem, Ashley-Edison have the ability to offer a solution from an extensive range of standard and custom built products.

 "The world comes to Ashley-Edison for power protection solutions, and we are equally keen to bring our experience and advice to you. We see our products on duty in all continents, facing some of the most rigorous environments. With our ever growing world network, there will be an Ashley-Edison office near you already. If not, contact us direct. We are internationally minded, and at your service." Ashley-Edison UK-Asia.



Overview

Total energy cost-saving solutions

reduce power costs by as much as 10-20% and extend equipment and motor life

There are very few desirable and many undesirable things that happen to electric motors and other electrical equipment as a result of operating a power system at or near the ends of voltage limits.The best motor life and most efficient operation usually occurs when motors are operated at voltages close to the nameplate ratings.

Over-voltage can drive up amperage and temperature even on lightly loaded motors. Motor life can be shortened significantly by high voltage.



  • Full load efficiency drops with either high or low voltage.

  • Power factor improves with lower voltage and drops sharply with high voltage.

  • Inrush current goes up with higher voltage


Save huge amounts on energy costs:



  • use MeterTrac to monitor power costs ...

  • use Ashley-Edison Automatic Voltage Optimisers to improve power supply.

This is how it works:

Step 1

Site survey.

MeterTrac power meters are used to measure and analyse each phase of the power supply to your sites. Data is converted into real-time visual display of your energy consumption.

step 2

Installation.

Highly qualified and experienced engineers will install your new Ashley Edison voltage optimisation equipment.

Step 3

Save energy and money!

Your equipment is now operating at optimum efficiency, lowering your energy bills and extending equipment life span.

Why use AVO?

Telecommunications

TV, radio, telephone transmitters, relay stations, radar installations, navigational beacons etc, all need dependable power for reliable operation.Many such facilities are in remote locations, supplied over long lines or even from their own generators. Ashley-Edison units are in service worldwide - with communication networks, even national security, depending on them

Computers and data

Computers and other electronic business systems are highly sensitive to power fluctuations. Even a brief voltage drop below design limits will upset logic circuits, bringing chaos to stored data, calculations etc. So the fast response Ashley Edison Automatic Voltage Regulators (AVRs) and Uninterruptible Power Supplies (UPS) are playing a major role in computer applications around the world

Industry

Many processes and production lines slow down and even stop as a result of power problems. With just a simple voltage drop welding equipment produces faulty welds, ovens and furnaces take far longer to heat up, electroplating processes lose their efficiency and the list goes on. This is why industrial plants worldwide look to Ashley-Edison for the solution to their power problems.

Refrigeration

When air-conditioning and

refrigeration systems experience any form of power disturbance, even just a minor voltage fluctuation, impaired performance or often system shutdown is the end result.

As a major international problem Ashley-Edison units are regularly relied upon to guarantee the availability of a clean and regulated power source.

Research

Electronic instruments play a major role in laboratory work and their measuring accuracy depends totally on the quality of power they receive. An abrupt voltage drop can invalidate the results from a costly research program. Today many world research establishments depend on Ashley Edison for ensuring the quality of their power supply whether it be for a single instrument or an entire laboratory.



How does AVO really work?

AVO solutions work by reducing incoming voltage down to a steady 230 volts which is the standard for all electrical devices (single phase) in Australia. AVO also works on three phase circuits.



Electricity suppliers deliver electricity to the switch room in your premises at anything between 240 volts and 253 volts, because they are obliged to increase the voltage to avoid losses during transmission from the power station and have Service Delivery Agreements for minimum voltage to customers.


Ashley-Edison AVO units will save you money on current energy utility costs if you have a constant over voltage supply. Ashley-Edison AVO units can also save you money on plant and equipment repair costs by extending electric motor life signifcantly.



A thorough site survey using a temporary installation of MeterTrac will determine whether it will be beneficial and we will provide you with a full report detailing estimated savings peranum. Typically these devices offer a payback between two to three years.



Ashley-Edison AVO units work by installing a secondary variable voltage transformer between existing transformer(s) and the LV power supply to main switch boards. The benefits are savings on electricity bills (which can be as much as 10 -20%) and reduced maintenance on equipment operating at a higher voltage than it was designed for.



OzGreen Energy Pty Ltd is proud to have been appointed exclusive agents for Ashley-Edison UK-Asia.products for Australia and New Zealand for all services relating to:

  • Design & Consultancy Advice
  • Site Assessments & Surveys
  • Installation
  • Commissioning
  • Technical Helpline / Support Desk
  • Repair Facility
  • Preventative Maintenance
  • 24 Hour On Site Emergency
  • Remedial Cover
  • Battery Maintenance and Replacement
  • Upgrade / Exchange
